Blue Sea 4160 SS Push Button Switch - Off-On - Blue - 10A

Blue Sea 4160 SS Push Button Switch - Off-On - Blue - 10A
$25.43

Availability: In stock

BLUE SEA 4160 SS PUSH BUTTON SWITCH 10A OFF-ON BLUE
OR
Description

Details

4160 SS Push Button Switch - Off-On - Blue - 10A

  • 10A continuous
  • Single Pole Double Throw or Single Pole Single Throw
  • Can be wired for normally open or normally closed
  • Installs with .110inch quick connects (included in retail package)

Specifications

  • Action: OFF-ON
  • Amperage: 10A @ 12V DC
  • Nominal Voltage: 12V DC
  • Maximum LED Operating Current: 20mA
  • Minimum Operating Temperature: -10° C
  • Maximum Operating Temperature: 70° C
  • Minimum Storage Temperature: -55° C
  • Maximum Storage Temperature: 85° C
  • Illumination: Independent – Separate contacts for LED power
  • Mounting Hole: 19mm
  • Switching Cycles: 18,000
  • Termination: 5 – 0.110inch Quick Connect terminals


Other Technical Specifications:

Throw/Pole = N/A
Color = N/A
Amps - Rating = N/A
Additional Information

Additional Information

Name Blue Sea 4160 SS Push Button Switch - Off-On - Blue - 10A
Condition New
Model 4160
Rebate Description N/A
Rebate Start Date N/A
Rebate End Date N/A
Brand Blue Sea Systems
UPC N/A
